PumpAlign is the premier pump alignment software designed for industrial maintenance engineers and technicians. Our tool enables precise shaft misalignment detection, vibration diagnostics, and predictive maintenance for pumps.
Shaft Alignment
The Shaft Alignment tool aids in detecting misalignment using four critical readings - Top, Bottom, Left, and Right (from motor side, see below). Optionally, input pipe strain and target alignment tolerance (can input 0) to get refined shim recommendations.
Output includes shim corrections for Front Left (FL), Front Right (FR), Rear Left (RL), Rear Right (RR) feet, adjusted automatically for pipe strain if provided, along with tolerance verification and a 2D alignment visualization.
NOTE: Left/Right readings are taken from the motor side facing the pump.
Soft Foot
The Soft Foot diagnostic tool assists in identifying uneven mounting feet pressure, a common cause of pump vibration and mechanical failures.
Enter pressure readings for each foot to identify any soft foot condition and receive inspection suggestions.
Foundation Looseness
Detect looseness in pump foundations causing vibration and instability. Input gap measurements to get diagnostic feedback.
Coupling Check
Evaluate coupling offset and angular misalignment to prevent failures and excessive vibration.
Bearing & Seal Condition
Diagnose bearing and seal condition from vibration amplitude and temperature inputs.
Rotor Unbalance
Evaluate rotor unbalance using vibration amplitude and rotational speed inputs.
Cavitation Check
Assess cavitation risk from pump noise level and flow rate inputs.
